SUK SK-BF tray cling film overwrapping equipment is a packaging option for food factories preparing products in trays. Start with the food product, tray dimensions, filled-product height and film sample to assess a suitable configuration.
The SK-BF reference packing speed is 20–60 packs per minute. Actual output depends on the tray, food product, film and selected machine settings; the upper speed should not be assumed for every tray size or product.
Request a Tray Wrapping Configuration
Inspection, labelling, weighing and other line equipment must be reviewed separately; they are not assumed to be included as standard.
Meat processors and fresh-produce packing facilities can request a tray and product assessment. Suitability depends on the actual food, tray and film combination, not the application name alone.
Cling film overwrapping is not the same process as vacuum packaging, modified-atmosphere tray sealing or horizontal flow wrapping. Do not assume that a cling-wrapped pack provides vacuum, gas flushing or a guaranteed shelf-life extension. State any preservation requirement separately for technical review.
Compare beef tray wrapping, seafood trays, fruit and vegetable trays or vegetable tray packaging. Provide the filled tray, film, product height and required finished-pack appearance.
Assess tray rigidity, rim condition, food stability, transfer and handling after wrapping. State any coding, weighing or labelling interface separately. Shelf-life, vacuum or modified-atmosphere requirements need a separate packaging assessment; cling overwrapping alone does not establish them. Send your tray and film samples for an SK-BF review.
Reference configuration: 2026 SUK catalog, printed page 22. The 20–60 packs/min speed is also confirmed by SUK. Confirm the final machine configuration with your filled tray and film samples before ordering.
| Model | SK-BF |
|---|---|
| Reference packing speed | 20–60 packs/min |
| Film width | 220–550 mm |
| Tray length | 100–250 mm |
| Tray width | 80–210 mm |
| Tray height | 18–60 mm |
| Product height | 5–80 mm |
| Power | 6 kW |
| Machine dimensions | 3980 × 1030 × 1450 mm |
| Machine weight | 700 kg |
These are catalog reference values, not a promise that every combination of maximum dimensions and highest speed can run simultaneously. The quotation should identify the agreed configuration and product test conditions.
Send these details for a useful quotation: food product and sample, tray length × width × height, filled-product height, tray material, film sample or specification, required packs per minute, cleaning and inspection needs, available space and installation country.
Need another bag format? Compare premade pouch packaging or vertical roll-film bag packaging. These handle different packaging formats and are not substitutes for every tray-wrapping project.
