product
Compare SUK stick-pack configurations for coffee premix, drink powders, sugar and liquid condiments. Choose powder, granule or liquid dosing to match the actual product; stick format can be single-lane or multi-lane. For a complete retail line, include sachet counting and cartoning in the project scope. Send your product sample, dose, finished stick dimensions, film and accepted packs per minute. We will review the configuration, changeover requirements and downstream connection before quotation.
A stick pack machine is selected around the narrow, single-serve pack your food factory needs to produce. Coffee premix, seasoning powders and liquid condiments require different dosing arrangements; one filling system should not be assumed to handle them all. A stick-pack project may use a single-lane or multi-lane configuration, depending on the reviewed pack and output requirements.
Start with your project: Choose your food application · Review the reference configuration · Prepare your quotation brief. Contact SUK with your sample and pack drawing.
Food applications to discuss include coffee premix, seasonings and single-serve liquid condiments. Product suitability depends on the specific formulation and configuration. Powder capacity in grams, liquid dose in millilitres and pump flow in litres/minute describe different quantities and must not be treated as interchangeable.
These pages describe configuration choices, not proof that the reference machine has run every listed formulation. For retail boxes, specify sticks per carton and accepted cartons per minute alongside the packer's output, then review the stick-pack counting and cartoning line.
Send your sample and pack drawing for a matched equipment proposal. Ask the quotation to define dosing, film tooling, change parts, installation and operator-training scope.
The following SKTB-120H table retains the existing website configuration reference. It is separate from the catalog SKTB-120QF, QY and HY records. A pump flow rate is not a per-stick dose or a finished-pack output figure. Confirm the actual product range, film compatibility, accuracy and sustained speed with the proposed configuration; maximum fill and maximum output are not guaranteed together.
| Model | SKTB-120H |
| Dosing Method | A: Powder and granule weighing and metering 1-30g; B: Piston pump 2-42ml; C: Magnetic pump 3Liter/min (for pure liquid or oil product) |
| Hopper type | A: Single layer SS304 hopper; B: Double jacket SS304 hopper; C: Magnetic pump hose connection to raw liquid tank |
| Packing speed | 20-45 bag/min |
| Bag Seal type | Stick /Bags |
| Cut type | A: Teeth cut; B: Straight cut C: Round cut D: Irregular cut (Stick Width within 40mm) |
| Film thickness | 0.05-0.1mm |
| Film material | Laminated film such as paper/PE, aluminum/PE, PA/PE, PET/PE, filter paper |
| Drive method | Electricity + Pneumatic |
| Control style | PLC control system+English/Chinese screen (Or customized panel) |
| Power | 1.8KW |
| Power supply | AC220V 1phase 50Hz/ AC380V 3phases 50Hz |
| Air consumption | 0.4cbm/min 0.8Mpa |
| Dimension | 750x710x1780 mm |
Related equipment: the vertical VFFS packaging machine for pillow and gusset bags, and the sachet powder packaging line for end-to-end sachet-to-carton production.
Send the food product/sample, target dose with its unit, required accuracy, stick width and length, film and target whole-machine output. Add lane requirements if known, desired cut, packs/carton and the destination factory utilities.
Review the multi-lane stick pack counting and cartoning line, compare DLA-400F powder reference data, or send your factory project to SUK.
