SUK’s Multi-Lane Powder Sachet Packaging Machine is designed for continuous packaging of single-serve powder sachets and narrow stick packs. It is intended for food ingredients, nutrition products, pharmaceutical powders, chemical powders and cosmetic powders where a factory needs several small packs produced in parallel.
The system uses multi-lane packaging architecture with powder dosing. The final configuration should be matched to the powder behavior, target fill quantity, sachet dimensions, film specification and required production rhythm. Send your product, target pack weight, sachet width and length, preferred pack format and target output for a configuration review.
Multi-lane equipment is designed to produce several narrow sachets or stick packs in parallel rather than one large bag at a time. This format is relevant for factory projects using individual powder portions, including beverage mixes, nutrition products, seasoning powders and similar dry products.
The correct production output cannot be calculated from a lane count alone. Powder flow, fill quantity, film structure, sachet size, dosing accuracy and operating conditions all affect the final result. For this reason, SUK reviews the real product and target pack specification before recommending a configuration.
Powder dosing suitability must be matched to the real product. Auger-style dosing is a common approach for controlled powder filling, but the final dosing configuration should be confirmed according to powder density, flow behavior, moisture sensitivity and the required fill range.
A food or nutrition factory should also consider access for cleaning, material changeover and inspection. The product-contact path, hopper, dosing section, film path and sealing area should be reviewed as one production process rather than as isolated machine components.
This product family is intended for narrow sachets and stick packs. The finished pack format, seal arrangement, tear feature and dimensions depend on the validated film and machine configuration. A packaging sample, pouch drawing or existing market pack is useful for a project review.
Do not treat a multi-lane sachet machine as a premade pouch machine. A premade pouch system uses ready-made stand-up or zipper pouches, while a multi-lane machine forms narrow single-serve packs from the selected film web.
The existing SUK product information identifies the following powder categories as relevant applications:
Before equipment selection, provide a product sample or detailed product description. Important variables include powder density, particle shape, flow behavior, moisture condition, target fill quantity, required sachet dimensions and the desired production schedule.
The following values are taken from the 2026 SUK catalog, page 21, for model DLA-400F, a multi-row powder packaging machine. Project-specific details should still be confirmed by the engineering team before quotation.
| Model | DLA-400F |
| Speed | 30–60 bags/min/line |
| Bag size | Length 40–170 mm; width 20–50 mm |
| Applicable film thickness | 0.08–0.12 mm |
| Maximum roll-film diameter | Max. 320 mm |
| Power | 2000 W |
| Packaging material | Aluminium composite film, OPP composite film, CPP composite film; examples BOPP/PE, PET/PE and PET/AL |
| Noise | ≤80 dB |
| Measurement range | 5–20 ml |
| Machine dimension | L 1000 × W 890 × H 1820 mm |
| Machine weight | 200 kg |
The catalog specification above covers the base DLA-400F platform. The following items still need to be confirmed for each project:
These details must be confirmed against the product, sachet specification and selected machine configuration.
A multi-lane powder sachet machine is used for narrow single-serve packs. The best project review starts with the desired finished pack, not just the machine name.
Please provide:
A multi-lane powder packaging project may connect with other equipment depending on the finished product and factory workflow:
The video title refers to a 2g powder sachet example. It must not be generalized as the machine’s universal fill range. Final capability is confirmed through product and packaging evaluation.
SUK’s existing product page lists food powders, nutritional supplements, pharmaceutical powders, chemical powders and cosmetic powders. The final suitability depends on the real powder’s flow behavior, density, moisture condition and target fill requirement.
The 2026 SUK catalog, page 21, describes the DLA-400F as a multi-row powder packaging machine. The final row and line configuration must be confirmed with the selected machine configuration and the required sachet dimensions.
The 2026 SUK catalog, page 21, states 30–60 bags per minute per line for the DLA-400F. Total output depends on the confirmed row and line configuration, powder, fill quantity, sachet size, film and operating conditions. The line definition and the final output should be confirmed during technical review rather than assumed.
Yes. SUK provides automatic cartoning equipment and packaging-line solutions. The required infeed, counting and cartoning arrangement depends on the finished sachet size, carton format and target line output.
Send the powder name, product sample or photo, target fill quantity, sachet dimensions, film information, target output, destination country, electrical standard and any required downstream equipment. This information helps SUK recommend a suitable machine configuration.
Send your powder sample, target pack weight, sachet dimensions and target production requirement to SUK Precision Machinery. The team can review the product and packaging requirement, then recommend a suitable multi-lane powder sachet configuration.
